python3+PyQt5自定义视图详解
pyqt提供的几个视图类都可以较好工作，包括QLisView，QTableView和QTreeView。但是对于一些难以用现有的方式来呈现数据，这时，可以创建我们自己的视图子类并将其用做模型数据的可视化来解决这一问题。本文通过Python3+pyqt5实现了python Qt GUI 快速编程的16章的例子。
#!/usr/bin/env python3
import gzip
import os
import platform
import sys
from PyQt5.QtCore import (QAbstractTableModel, QDateTime, QModelIndex,
QSize, QTimer, QVariant, Qt,pyqtSignal)
from PyQt5.QtGui import ( QColor, QCursor, QFont,
QFontDatabase, QFontMetrics, QPainter, QPalette, QPixmap)
from PyQt5.QtWidgets import QApplication,QDialog,QHBoxLayout, QLabel, QMessageBox,QScrollArea, QSplitter, QTableView,QWidget
(TIMESTAMP, TEMPERATURE, INLETFLOW, TURBIDITY, CONDUCTIVITY,
COAGULATION, RAWPH, FLOCCULATEDPH) = range(8)
TIMESTAMPFORMAT = "yyyy-MM-dd hh:mm"
class WaterQualityModel(QAbstractTableModel):
def __init__(self, filename):
super(WaterQualityModel, self).__init__()
self.filename = filename
self.results = []
def load(self):
self.beginResetModel()
exception = None
fh = None
try:
if not self.filename:
raise IOError("no filename specified for loading")
self.results = []
line_data = gzip.open(self.filename).read()
for line in line_data.decode("utf8").splitlines():
parts = line.rstrip().split(",")
date = QDateTime.fromString(parts[0] + ":00",
Qt.ISODate)
result = [date]
for part in parts[1:]:
result.append(float(part))
self.results.append(result)
except (IOError, ValueError) as e:
exception = e
finally:
if fh is not None:
fh.close()
self.endResetModel()
if exception is not None:
raise exception
def data(self, index, role=Qt.DisplayRole):
if (not index.isValid() or
not (0 <= index.row() < len(self.results))):
return QVariant()
column = index.column()
result = self.results[index.row()]
if role == Qt.DisplayRole:
item = result[column]
if column == TIMESTAMP:
#item = item.toString(TIMESTAMPFORMAT)
item=item
else:
#item = QString("%1").arg(item, 0, "f", 2)
item = "{0:.2f}".format(item)
return item
elif role == Qt.TextAlignmentRole:
if column != TIMESTAMP:
return QVariant(int(Qt.AlignRight|Qt.AlignVCenter))
return QVariant(int(Qt.AlignLeft|Qt.AlignVCenter))
elif role == Qt.TextColorRole and column == INLETFLOW:
if result[column] < 0:
return QVariant(QColor(Qt.red))
elif (role == Qt.TextColorRole and
column in (RAWPH, FLOCCULATEDPH)):
ph = result[column]
if ph < 7:
return QVariant(QColor(Qt.red))
elif ph >= 8:
return QVariant(QColor(Qt.blue))
else:
return QVariant(QColor(Qt.darkGreen))
return QVariant()
def headerData(self, section, orientation, role=Qt.DisplayRole):
if role == Qt.TextAlignmentRole:
if orientation == Qt.Horizontal:
return QVariant(int(Qt.AlignCenter))
return QVariant(int(Qt.AlignRight|Qt.AlignVCenter))
if role != Qt.DisplayRole:
return QVariant()
if orientation == Qt.Horizontal:
if section == TIMESTAMP:
return "Timestamp"
elif section == TEMPERATURE:
return "\u00B0" +"C"
elif section == INLETFLOW:
return "Inflow"
elif section == TURBIDITY:
return "NTU"
elif section == CONDUCTIVITY:
return "\u03BCS/cm"
elif section == COAGULATION:
return "mg/L"
elif section == RAWPH:
return "Raw Ph"
elif section == FLOCCULATEDPH:
return "Floc Ph"
return int(section + 1)
def rowCount(self, index=QModelIndex()):
return len(self.results)
def columnCount(self, index=QModelIndex()):
return 8
class WaterQualityView(QWidget):
clicked = pyqtSignal(QModelIndex)
FLOWCHARS = (chr(0x21DC), chr(0x21DD), chr(0x21C9))
def __init__(self, parent=None):
super(WaterQualityView, self).__init__(parent)
self.scrollarea = None
self.model = None
self.setFocusPolicy(Qt.StrongFocus)
self.selectedRow = -1
self.flowfont = self.font()
size = self.font().pointSize()
if platform.system() == "Windows":
fontDb = QFontDatabase()
for face in [face.toLower() for face in fontDb.families()]:
if face.contains("unicode"):
self.flowfont = QFont(face, size)
break
else:
self.flowfont = QFont("symbol", size)
WaterQualityView.FLOWCHARS = (chr(0xAC), chr(0xAE),
chr(0xDE))
def setModel(self, model):
self.model = model
#self.connect(self.model,
# SIGNAL("dataChanged(QModelIndex,QModelIndex)"),
# self.setNewSize)
self.model.dataChanged.connect(self.setNewSize)
#self.connect(self.model, SIGNAL("modelReset()"), self.setNewSize)
self.model.modelReset.connect(self.setNewSize)
self.setNewSize()
def setNewSize(self):
self.resize(self.sizeHint())
self.update()
self.updateGeometry()
def minimumSizeHint(self):
size = self.sizeHint()
fm = QFontMetrics(self.font())
size.setHeight(fm.height() * 3)
return size
def sizeHint(self):
fm = QFontMetrics(self.font())
size = fm.height()
return QSize(fm.width("9999-99-99 99:99 ") + (size * 4),
(size / 4) + (size * self.model.rowCount()))
def paintEvent(self, event):
if self.model is None:
return
fm = QFontMetrics(self.font())
timestampWidth = fm.width("9999-99-99 99:99 ")
size = fm.height()
indicatorSize = int(size * 0.8)
offset = int(1.5 * (size - indicatorSize))
minY = event.rect().y()
maxY = minY + event.rect().height() + size
minY -= size
painter = QPainter(self)
painter.setRenderHint(QPainter.Antialiasing)
painter.setRenderHint(QPainter.TextAntialiasing)
y = 0
for row in range(self.model.rowCount()):
x = 0
if minY <= y <= maxY:
painter.save()
painter.setPen(self.palette().color(QPalette.Text))
if row == self.selectedRow:
painter.fillRect(x, y + (offset * 0.8),
self.width(), size, self.palette().highlight())
painter.setPen(self.palette().color(
QPalette.HighlightedText))
#timestamp = self.model.data(
#self.model.index(row, TIMESTAMP)).toDateTime()
timestamp = self.model.data(self.model.index(row, TIMESTAMP))
painter.drawText(x, y + size,
timestamp.toString(TIMESTAMPFORMAT))
#print(timestamp.toString(TIMESTAMPFORMAT))
x += timestampWidth
temperature = self.model.data(
self.model.index(row, TEMPERATURE))
#temperature = temperature.toDouble()[0]
temperature = float(temperature)
if temperature < 20:
color = QColor(0, 0,
int(255 * (20 - temperature) / 20))
elif temperature > 25:
color = QColor(int(255 * temperature / 100), 0, 0)
else:
color = QColor(0, int(255 * temperature / 100), 0)
painter.setPen(Qt.NoPen)
painter.setBrush(color)
painter.drawEllipse(x, y + offset, indicatorSize,
indicatorSize)
x += size
rawPh = self.model.data(self.model.index(row, RAWPH))
#rawPh = rawPh.toDouble()[0]
rawPh = float(rawPh)
if rawPh < 7:
color = QColor(int(255 * rawPh / 10), 0, 0)
elif rawPh >= 8:
color = QColor(0, 0, int(255 * rawPh / 10))
else:
color = QColor(0, int(255 * rawPh / 10), 0)
painter.setBrush(color)
painter.drawEllipse(x, y + offset, indicatorSize,
indicatorSize)
x += size
flocPh = self.model.data(
self.model.index(row, FLOCCULATEDPH))
#flocPh = flocPh.toDouble()[0]
flocPh = float(flocPh)
if flocPh < 7:
color = QColor(int(255 * flocPh / 10), 0, 0)
elif flocPh >= 8:
color = QColor(0, 0, int(255 * flocPh / 10))
else:
color = QColor(0, int(255 * flocPh / 10), 0)
painter.setBrush(color)
painter.drawEllipse(x, y + offset, indicatorSize,
indicatorSize)
painter.restore()
painter.save()
x += size
flow = self.model.data(
self.model.index(row, INLETFLOW))
#flow = flow.toDouble()[0]
flow = float(flow)
char = None
if flow <= 0:
char = WaterQualityView.FLOWCHARS[0]
elif flow < 3.6:
char = WaterQualityView.FLOWCHARS[1]
elif flow > 4.7:
char = WaterQualityView.FLOWCHARS[2]
if char is not None:
painter.setFont(self.flowfont)
painter.drawText(x, y + size, char)
painter.restore()
y += size
if y > maxY:
break
def mousePressEvent(self, event):
fm = QFontMetrics(self.font())
self.selectedRow = event.y() // fm.height()
self.update()
#self.emit(SIGNAL("clicked(QModelIndex)"),
# self.model.index(self.selectedRow, 0))
self.clicked.emit(self.model.index(self.selectedRow, 0))
def keyPressEvent(self, event):
if self.model is None:
return
row = -1
if event.key() == Qt.Key_Up:
row = max(0, self.selectedRow - 1)
elif event.key() == Qt.Key_Down:
row = min(self.selectedRow + 1, self.model.rowCount() - 1)
if row != -1 and row != self.selectedRow:
self.selectedRow = row
if self.scrollarea is not None:
fm = QFontMetrics(self.font())
y = fm.height() * self.selectedRow
print(y)
self.scrollarea.ensureVisible(0, y)
self.update()
#self.emit(SIGNAL("clicked(QModelIndex)"),
# self.model.index(self.selectedRow, 0))
self.clicked.emit(self.model.index(self.selectedRow, 0))
else:
QWidget.keyPressEvent(self, event)
class MainForm(QDialog):
def __init__(self, parent=None):
super(MainForm, self).__init__(parent)
self.model = WaterQualityModel(os.path.join(
os.path.dirname(__file__), "waterdata.csv.gz"))
self.tableView = QTableView()
self.tableView.setAlternatingRowColors(True)
self.tableView.setModel(self.model)
self.waterView = WaterQualityView()
self.waterView.setModel(self.model)
scrollArea = QScrollArea()
scrollArea.setBackgroundRole(QPalette.Light)
scrollArea.setWidget(self.waterView)
self.waterView.scrollarea = scrollArea
splitter = QSplitter(Qt.Horizontal)
splitter.addWidget(self.tableView)
splitter.addWidget(scrollArea)
splitter.setSizes([600, 250])
layout = QHBoxLayout()
layout.addWidget(splitter)
self.setLayout(layout)
self.setWindowTitle("Water Quality Data")
QTimer.singleShot(0, self.initialLoad)
def initialLoad(self):
QApplication.setOverrideCursor(QCursor(Qt.WaitCursor))
splash = QLabel(self)
pixmap = QPixmap(os.path.join(os.path.dirname(__file__),
"iss013-e-14802.jpg"))
#print(os.path.join(os.path.dirname(__file__),
# "iss013-e-14802.jpg"))
splash.setPixmap(pixmap)
splash.setWindowFlags(Qt.SplashScreen)
splash.move(self.x() + ((self.width() - pixmap.width()) / 2),
self.y() + ((self.height() - pixmap.height()) / 2))
splash.show()
QApplication.processEvents()
try:
self.model.load()
except IOError as e:
QMessageBox.warning(self, "Water Quality - Error", e)
else:
self.tableView.resizeColumnsToContents()
splash.close()
QApplication.processEvents()
QApplication.restoreOverrideCursor()
app = QApplication(sys.argv)
form = MainForm()
form.resize(850, 620)
form.show()
app.exec_()
运行结果：
