python实现五子棋游戏（pygame版）
本文实例为大家分享了python五子棋游戏的具体代码，供大家参考，具体内容如下
目录
- 简介
- 实现过程
- 结语
简介
使用python实现pygame版的五子棋游戏；
环境：Windows系统+python3.8.0
游戏规则：
1.分两位棋手对战，默认黑棋先下；当在棋盘点击左键，即在该位置绘制黑棋；
2.自动切换到白棋，当在棋盘点击左键，即在该位置绘制白棋；
3.轮流切换棋手下棋，当那方先形成5子连线者获胜（横、竖、斜、反斜四个方向都可以）。
游戏运行效果如下：
实现过程
1.新建文件settings.py，用来定义一些必须的基本属性和初始值；
class Settings(): def __init__(self): """初始化的游戏配置""" # 屏幕宽高 self.width = 700 self.height = 554 # 文字颜色和大小 self.fontsize = 14 self.fonttype = 'simsunnsimsun' # 棋盘格数 self.number = 15 # 棋盘左边距、上边距和间隔 self.bd_left = 30 self.bd_top = 30 self.bd_space = 36 # 判断游戏是否结束（默认开始） self.game_active = True # 判断哪方下棋（默认黑子先写） self.chess_player = 1 self.prompt_info = '当前棋手：黑棋' # 开始校验输赢（两边合计9，因为已经有一边5步） self.win_number = 0 # 设置背景图、黑棋图片、白棋图片路径 self.checkerboard_bg = 'images/checkerboard_bg.png' self.black_chess = 'images/black_chess.png' self.white_chess = 'images/white_chess.png' # 存储落子数据 self.move_chess = []
2.新建文件checkerboard.py，主要用来绘制背景图和棋格线；
import sys
import pygame
class Checkerboard():
def __init__(self, ck_settings, screen, position):
self.ck_settings = ck_settings
self.screen = screen
self.position = position
# 颜色和坐标大小
self.text_color = (0, 0, 0)
self.font = pygame.font.SysFont(ck_settings.fonttype, ck_settings.fontsize)
# 存储棋子坐标
self.checkerboard = []
# 加载背景图、黑棋和白棋（当有图片不存在时，打印错误并退出游戏）
try:
self.bg_image = pygame.image.load(ck_settings.checkerboard_bg)
self.black_image = pygame.image.load(ck_settings.black_chess).convert_alpha() # convert_alpha背景透明
self.white_image = pygame.image.load(ck_settings.white_chess).convert_alpha()
self.chess_rect = self.black_image.get_rect()
except Exception as e:
print('error:', e)
sys.exit()
def draw_board(self):
# 存储棋子坐标
for i in range(self.ck_settings.number):
self.checkerboard.append([])
for j in range(self.ck_settings.number):
self.checkerboard[i].append(self.position(self.ck_settings.bd_left + i * self.ck_settings.bd_space, self.ck_settings.bd_top + j * self.ck_settings.bd_space))
# 绘制棋盘坐标
for i in range(0, self.ck_settings.number):
# ord返回字符的ASCII数值，chr再返回字符
x_text = self.font.render(chr(ord('A') + i), True, self.text_color) # A-O
y_text = self.font.render(str(i + 1), True, self.text_color) # 1-15
# 绘制xy轴坐标（在棋盘背景图绘制）
self.bg_image.blit(x_text, (self.checkerboard[i][0].x - x_text.get_width() / 2, self.checkerboard[i][0].y - 20))
self.bg_image.blit(y_text, (self.checkerboard[0][i].x - 20, self.checkerboard[0][i].y - y_text.get_height() / 2))
# 绘制横竖线（在棋盘背景图绘制）
pygame.draw.line(self.bg_image, self.text_color, self.checkerboard[0][i], self.checkerboard[self.ck_settings.number-1][i])
pygame.draw.line(self.bg_image, self.text_color, self.checkerboard[i][0], self.checkerboard[i][self.ck_settings.number-1])
# 绘制棋盘背景图
self.screen.blit(self.bg_image, (0, 0))
3.新建文件infopanel.py，主要用来绘制棋盘右边提示信息（暂时只有显示下棋方和获胜信息）；
import pygame.font class Infopanel(): def __init__(self, ck_settings, screen): """初始化属性""" self.settings = ck_settings self.screen = screen self.screen_rect = screen.get_rect() # 设置文字颜色和字体大小 self.info_color = (217, 8, 10) self.font = pygame.font.SysFont(ck_settings.fonttype, 16) def draw_info(self, info): """将文字渲染为图像，并定位到右边水平居中""" self.info_image = self.font.render(info, True, self.info_color) self.info_image_rect = self.info_image.get_rect() self.info_image_rect.right = self.screen_rect.right - (self.screen_rect.width - 536 - self.info_image_rect.width) / 2 self.info_image_rect.top = 50 # 绘制到屏幕 self.screen.blit(self.info_image, self.info_image_rect)
4.新建文件“game_functions.py”，存放跟游戏有关的所有业务逻辑函数；
import sys
import pygame
# 棋
def update_board(ck_settings, cb, index_coordinates, position):
"""更新棋盘信息"""
# 判断棋手（黑棋或白棋）
if ck_settings.chess_player == 1:
ck_settings.prompt_info = '当前棋手：白棋'
img = cb.black_image
chess_type = 'black'
else:
ck_settings.prompt_info = '当前棋手：黑棋'
img = cb.white_image
chess_type = 'white'
"""落棋"""
dropState = check_at(ck_settings, index_coordinates)
if dropState:
i, j = index_coordinates
chess_x = cb.checkerboard[j][i].x - cb.chess_rect.width / 2
chess_y = cb.checkerboard[j][i].y - cb.chess_rect.height / 2
# 累计步数（两边合计）
ck_settings.win_number += 1
# 落子并转换棋手
ck_settings.move_chess.append({'type': chess_type, 'coord': position(i, j)})
cb.bg_image.blit(img, (chess_x, chess_y))
ck_settings.chess_player *= -1
# 合计9步开始校验输赢
if ck_settings.win_number >= 9:
check_stats(ck_settings, (i, j))
else:
ck_settings.prompt_info = '已经有其他棋子'
# 检查(i,j)位置是否已占用
def check_at(ck_settings, index_coordinates):
for item in ck_settings.move_chess:
if index_coordinates == item['coord']:
return False
return True
def check_stats(ck_settings, pos):
"""校验四个方向，是否有了输赢"""
pos_i, pos_j = pos
directs = [(1, 0), (0, 1), (1, 1), (1, -1)] # 横、竖、斜、反斜 四个方向检查
for direct in directs:
line_checkerboard = []
d_x, d_y = direct
last = ck_settings.move_chess[-1]
line_ball = [] # 存放在一条线上的棋子
for ball in ck_settings.move_chess:
# 跟最后落子判断
if ball['type'] == last['type']:
x = ball['coord'].x - last['coord'].x
y = ball['coord'].y - last['coord'].y
if d_x == 0:
if x == 0:
line_ball.append(ball['coord'])
if d_y == 0:
if y == 0:
line_ball.append(ball['coord'])
if x * d_y == y * d_x:
line_ball.append(ball['coord'])
if len(line_ball) >= 5: # 只有5子及以上才继续判断
sorted_line = sorted(line_ball)
for i, item in enumerate(sorted_line):
index = i + 4
if index < len(sorted_line):
if d_x == 0:
y1 = item.y
y2 = sorted_line[index].y
# 此点和第5个点比较y值，如相差为4则连成5子
if abs(y1 - y2) == 4:
ck_settings.prompt_info = '黑棋获胜' if last['type'] == 'black' else '白棋获胜'
else:
x1 = item.x
x2 = sorted_line[index].x
# 此点和第5个点比较x值，如相差为4则连成5子
if abs(x1 - x2) == 4:
ck_settings.prompt_info = '黑棋获胜' if last['type'] == 'black' else '白棋获胜'
else:
break
# 事件
def check_events(ck_settings, cb, position):
"""监听事件"""
for event in pygame.event.get():
if event.type == pygame.QUIT:
sys.exit()
elif event.type == pygame.MOUSEBUTTONDOWN:
# 点击左键
if event.button == 1:
pos = pygame.mouse.get_pos() # 获取点击实际坐标
# 判断是否溢出
x_first = cb.checkerboard[0][0].x
x_last = cb.checkerboard[ck_settings.number - 1][ck_settings.number - 1].x
y_first = cb.checkerboard[0][0].y
y_last = cb.checkerboard[ck_settings.number - 1][ck_settings.number - 1].y
if pos[0] < x_first or pos[0] > x_last or pos[1] < y_first or pos[1] > y_last:
ck_settings.prompt_info = '落子位置不正确！'
else:
index_coordinates = to_index(ck_settings, pos)
update_board(ck_settings, cb, index_coordinates, position)
def to_index(ck_settings, pos):
"""实际坐标转换为棋盘下标"""
i = round((pos[1] - ck_settings.bd_top) / ck_settings.bd_space)
j = round((pos[0] - ck_settings.bd_left) / ck_settings.bd_space)
return (i, j)
5.新建文件gobang.py，主函数用来初始化程序，并同步更新程序的信息；
import pygame
from settings import Settings
from checkerboard import Checkerboard
from collections import namedtuple
import game_functions as gf
from infopanel import Infopanel
def run_game():
"""运行游戏"""
# 初始化游戏屏幕
pygame.init()
# 创建时钟对象 (可以控制游戏循环频率)
clock = pygame.time.Clock()
# 配置实例化
ck_settings = Settings()
screen = pygame.display.set_mode((ck_settings.width, ck_settings.height))
pygame.display.set_caption('五子棋游戏')
# namedtuple创建类似于元组的数据类型，除了可以用索引访问，能够迭代，还能用属性名访问数据
position = namedtuple('Position', ['x', 'y'])
# 创建实例
cb = Checkerboard(ck_settings, screen, position)
# 实例化面板信息
infopanel = Infopanel(ck_settings, screen)
while ck_settings.game_active:
# 绘制棋盘
cb.draw_board()
# 绘制面板信息
infopanel.draw_info(ck_settings.prompt_info)
# 检查玩家事件并更新棋盘
gf.check_events(ck_settings, cb, position)
# 让最近绘制的屏幕可见
pygame.display.flip()
# 通过时钟对象指定循环频率
clock.tick(60) # 每秒循环60次
run_game()
6.在文件gobang.py目录路径下，执行命令“python gobang.py”弹出窗口，即可对其操作游玩。
结语
该游戏只是实现了基础功能，还有很多可优化的功能：
1.根据实际情况加上更详细的面板信息（比如倒计时等）；
2.加上开始游戏按钮，可参考前面python实例；
3.胜负榜单等，可参考前面python实例。
